Meters & Counters
Display
Measurements
Measurements ranges and resolution
HMC8012
Digital Multimeter
5¾ digits (480K counts)
Up to 3 values simultaneously
Color TFT
Voltage, current, frequency, power, resistance (2 and 4 wire), temperature, capacitance, diode, continuity
- Voltage (DC/AC): 400 mV to 1000 V/750 V
(5 ranges, resolution: 1 µV)
- Current (DC/AC): 20 mA to 10 A
(4 ranges, resolution: 100 nA)
- Resistance: 400 Ω to 250 MΩ
- Capacitance: 5 nF to 500 µF
(6 ranges, resolution: 1pF
HM8112-3
Digital Multimeter
(DISCONTINUED)
6½ digits (1.2M counts)
Monochrome LCD
Voltage, current, resistance (2- and 4-wire), temperature, frequency/period, diode, continuity
- Voltage (DC/AC): 100 mV to 600 V
(5 ranges, resolution: 100 nV)
- Current (DC/AC): 100 µA to 1 A
(5 ranges, resolution: 100 pA)
- Resistance: 100 Ω to 10 MΩ
(6 ranges, resolution: 100 µΩ)
- Temperature: -270˚C to 1372˚C (depending on
sensor, resolution: 0.1˚C)
5 digits
2 values simultaneously
Monochrome LCD
HM8118
200 kHz LCR bridge/meter
inductance, capacitance, resistance, impedance, reactance,admittance, conductance, susceptance, quality factor, phase angle, phase difference, ratio
- impedance: 3 Ω to 100 MΩ
(6 ranges, resolution: 100 µΩ)
- Phase: -90˚ to +90˚
(resolution: 0.001˚)
- Frequency range: 20 Hz to 200 kHz
- Amplitude: 50 mV to 1.5 V (RMS)
- Internal bias voltage: 0 V to +5 V
- Internal bias current: 0 A to _200 mA
10 digits
Monochrome LCD
HM8123
3 GHz universal counter
frequency/period, pulse
width, duty cycle, UPM,
events, frequency ratio,
time interval, time difference,
phase difference
Frequency range: DC to 3 GHz)
Period: 5 ns to 10 000 s
HMC8015
Power Analyzer
5 digits
6 or 10 values simultaneously
Harmonics as bargraph (option)
Graphical signal trend (option), trend chart (option)
Color TFT
voltage, current, active
power, apparent power,
reactive power, power
factor, phase shift, frequency,
THD, energy, extended analysis (option)
Voltage: 15 V to 1800 V
(peak, 7 ranges, resolution: 100 μV)
Current: 15 mA to 60 A
(peak, 12 ranges, resolution: 100 nA)
2 × 16 values
Monochrome LCD
Display adjustable in 5 steps (max. to off)
frequency, power,
VSWR, OTA, DTF, voice
reporting
Frequency range: 25 MHz to 500 MHz
Power measurement range: 0.1 W to 50 W
OTA dynamic range: 60 dB
DTF measurement ranges: 3 m to 120 m/240 m/480 m, (default: 120 m)
CTH200A
Portable Radio Test Set
